2" 110V AC Stainless Steel Solenoid Valve N/O

SKU: NOS2-110VAC

Availability: In Stock

No reviews yet
$298.95

Quick Links

Technical Details

SKU NOS2-110VAC
Position
Port Size
Voltage
Body Material
Components
Seal Material Viton® Diaphragm
Orifice Size
Temp Range
Pressure Range
Flow Rate
Power
Coil Connection
Response Time Fast Acting (Less than one second)
Duty Cycle 100% but not indefinitely
*Suitable Media Water – Air - Fuel - *Etc
Weight
Height
Length port to port
Width

Product Overview

The Model# NOS2-110VAC is a 2-way Normally open Stainless Steel solenoid valve. This valve has a 2" NPT input and output port with a directional arrow molded to the body that indicates the direction of flow. This valve will not close unless 0.50 amps or 40 watts of 110/120 volt AC power is supplied. When power is removed from the valve it will return to the open position. This valve includes a Viton seal and stainless steel body making it suitable for potable water, gas, glycol, diesel fuel, air, etc.

Model# NOS2-110VAC

Specification Overview
Temperature Range 15 to 265° F -10 to 130°C
Pressure Range 0 - 90 PSI (No Minimum Pressure)
Flow Rate Cv 45 (Appx 345 GPM @ 60 PSI)
Power Requirements 40 Watts 0.50 Amp
Response Time Fast Acting  (Less than one second)
Duty Cycle 100% but not indefinitely
*Suitable Media Water – Air - Fuel - Etc

 *Consult a chemical compatibility expert for correct seal and valve body material choice.

Valve Details
Function Normally Open
Port Size 2” Inch Female NPT
Valve Body 304 Stainless
Seal Material Viton® Diaphragm
Components Stainless Steel
Operation Type Semi-Direct Lift Valve
Coil Connection DIN with lead wires
Orifice Size 50mm
Weight 7 lb 8 oz
Height 7.50"
Length 5.30" port to port
Width 4.25"
