1/4" 12V DC Electric Brass Solenoid Valve

  • Image 1
  • Image 2
  • Image 3
  • Image 4
Price:
$25.95
SKU:
RSSM-3-12V
Availability:
In Stock
Shipping:
Calculated at checkout


Product Description

  • High Quality Solid Brass Body
  • 2-way normally closed operation
  • Easily attaches with 5mm machine screws
  • 90 Day Replacement Warranty
  • CE/ISO Certificated
  • 1/4'' Female NPT Thread

Model# RSSM-3-12VDC


Specifications:



Port Size

   1/4’’

Voltage

   12V DC Coil

Build Material

   Brass

Working Medium

   Water – Air – Gas – Diesel Fuel

Operation Mode

   Normally Closed

Fluid Viscosity

   Low Viscosity Fluids, Vacuum (below 20 cst)

Pressure Limits

   Air: 145 psi | Water: 115 psi | Light Oil: 70 psi

Temperature

   25 to 200° F

Seal Material

   NBR (Nitrile Butadiene Rubber)

Response Time

   Fast Acting  (Less than one second)



RSSM-3 is currently our smallest brass bodied valve in our brass valve line. This quarter inch valve is a two-way, direct acting valve with a normally closed operating position. This means that there are two ports in which media flows, the valve will open when energized and allow media to pass through. Taking the energy away from the valve will close it and stop the flow. This 1/4 inch valve works ideally with air, other pneumatic applications as well as water. It works across various other low viscosity media such as hot water, gas, diesel fuel, alcohol, kerosene, Freon, weak acids and weak alkali. The valve features a heavy duty, solid brass body that’s sure to last in the most strenuous projects.

This specific valve has a port size that is 1/4” inch female NPT threaded which is US standard. The orifice size is 3mm and CV value is 0.4. This valve is not recommended for gravity fed systems because of the small orifice size. The seal material is NBR (Buna-N) or Nitrile Butadiene Rubber.

This specific valve has a 12 VDC coil with a voltage range that is -+ 10. The coil head is fitted with a 14’’ wire lead that can easily be connected with your own choice of terminals. The top of the coil features a label that indicates the valve type and specifications. Its response time is very low; in fact, it acts in less than one second, making it a great choice for all types of applications.

This model works best mounted in an upright position with the coil on top. The body features a stamped arrow on the valve body to indication the direction of flow. The valve body is threaded at the base and can quickly be mounted with 5mm machine screws. It comes with a 90 day replacement warranty and is ISO/CE certified, which means one does not have to worry about quality when purchasing it.

Customers commonly use the RSSM-3 Valve for Water Filters, Ice Makers, Drinking Fountains, Washing Machines, Dishwashers, Dental Tools, Fish Tanks, Beer Brewing, Hydroponics, HVAC and Plumbing.



Find Similar Products by Category


Write your own product review

Product Reviews

  1. Does the job 5 Star Review

    Posted by on 8th Feb 2017

    Great service and a great product.


  2. Product worked as specified 5 Star Review

    Posted by on 29th Jul 2016

    I needed to replace the electric propane gas valve on my sailboat. I couldn't find the original part number at Parker Hannifin, so I found what I needed here at ordered it. Replaced valve works perfectly.


  3. nice valve! 5 Star Review

    Posted by on 30th Nov 2015

    The valve feels good in hand appears to be built well. The information on placard on top of valve little confusing and the voltage rating not written there you just have to remember what you ordered


  4. solenoid very good 5 Star Review

    Posted by on 12th Oct 2015

    Excellent product and delivery


  5. Quality product at a great price. 5 Star Review

    Posted by on 6th Jun 2015

    I use this for my on board air system and my air springs in my truck. It fits the bill and performs flawlessly.


  6. gtreat 5 Star Review

    Posted by on 29th Jan 2015

    the vacuum headlight covers on my car creep up after a few hours put this in line and walllaaa no more headlights going up. hit the switch and everything is back to normal. Guess I have a vacuum leak somewhere up the line but couldn't find it this did the trick
    Thanks


  7. Great product! 5 Star Review

    Posted by on 6th Dec 2014

    I installed the valve in the gasoline line of my very old winch truck, making it a hybrid so an alternative fuel can be used. It works "like a charm." Supplier had the part on order, notified me when it became available as promised! A real person was always available for information or questions. Doing business with you is a PLEASURE!
